RAM® Tough-Wedge™ with Double Socket Arm and Round Plate
Part#:RAM-B-407-C-202U UPC:793442949036
Ball Icon B SIZE
Arm Icon LONG ARM
1 949 kr
The RAM-B-407-C-202U consists of the Tough-Wedge™ 1" ball diamond base, long double socket arm and round base. The Tough-Wedge™ is a seat wedge mount that fits in the gap between the vehicle seat and center console allowing easy access and operation of your mobile device. The Tough-Wedge™ can also be used for back-seat applications, inserted into the pockets located on the back of the front seats. The mount is designed with a RAM 1" diameter patented rubber ball and socket system that has adjustment points at both ends of the double socket arm. The long length double socket arm measures 6" and will connect to all RAM cradles/adapters with a 1" ball. The 2.5" round base contains the universal AMPs hole pattern.
hardware included

Assembly Hardware

wedge dimensions

Length: 13.25"
Height: 8.25"
Thickness: 1"

socket to socket length

5.31"

hole pattern

4-Hole AMPS: 1.181" x 1.496"
3-Hole 120-Degree: 1.812" Diameter

ball size

B Size (1")

weight capacity

Standard Use: 2 lbs
Heavy-Duty Use: 1 lb

materials

Marine-grade aluminum
High strength composite

packaging type

Poly Bag

Weight

0.916 kg

Consists of
