RAM® Tough-Mag™ Heavy Duty Magnetic Mount with Round Plate - Short
Part#:RAM-101-B-MAG88U UPC:793442025082
Arm Length
Short Arm Medium Arm
Ball size C
2 189 kr
Incl. VAT

On request

This item is available on request. Leave your email and/or phone number and we’ll get back to you — it may already be on order or ready to assemble from parts in stock. If we need to source it specially, lead time is typically 6–8 weeks.

Looking for a faster option? Alternatives such as components or a different arm length are often available — contact us and we’ll help you find the right fit.

  • Magnetic or drill-down mounting solution secure your device to one end and the other to your preferred surface
  • Includes one round ball base, one Tough-Mag™ base, and one C size short length double socket arm ball and socket technology allows for near-infinite adjustability
  • RAM® Tough-Mag™ 88mm base magnetizes to any ferrous metal surface
  • Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments
  • Backed by a lifetime warranty
The RAM® Tough-Mag™ Heavy Duty Magnetic Mount with Round Plate - Short (RAM-101-B-MAG88U) features a short length double socket arm, one 2.5" diameter round base, and one RAM® Tough-Mag™ base. This heavy duty magnetic solution features C size components from our patented rubber ball and socket system, allowing the system to adjust at both ends of the socket arm. The rubber ball and socket technology allows for almost infinite adjustment to provide ideal viewing angles and dampens shock and vibration to extend the life of your device. The RAM® Tough-Mag™ features 10 industrial-strength N52 grade magnets that magnetize to any ferrous metal surface and rubber coating that protects the metal surface you're attaching to.
product dimensions

Overall Height: 5.54"
socket to socket length

2.5"
hole pattern

4-Hole AMPS: 1.181" x 1.496"
3-Hole 120-Degree: 1.812" Diameter
plate size

Top Plate: 2.5" Diameter
Magnetic Base: 3.46" Diameter
ball size

C Size (1.5")
weight capacity

Standard Use: 4 lbs
Heavy-Duty Use: 3 lbs
materials

Marine-grade aluminum
N52 Magnets (Qty 10)
packaging type

Poly Bag
Weight

0.585 kg
