Locking GDS® Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSki

Locking GDS® Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSkin®

Part#:RAM-GDS-DOCKL-ZE20PD2U UPC:793442202568 Patented & Pats. Pend.

RAM-GDS-DOCKL-ZE20PD2U:RAM-GDS-DOCKL-ZE20PD2U_2:Locking GDS Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSkin

RAM-GDS-DOCKL-ZE20PD2U:RAM-GDS-DOCKL-ZE20PD2U_3:Locking GDS Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSkin

RAM-GDS-DOCKL-ZE20PD2U:RAM-GDS-DOCKL-ZE20PD2U_4:Locking GDS Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSkin

RAM-GDS-DOCKL-ZE20PD2U:RAM-GDS-DOCKL-ZE20PD2U_5:Locking GDS Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSkin

Locking GDS® Dock + Dual USB for Zebra ET401 & ET4x 8" with IntelliSkin®

Part#:RAM-GDS-DOCKL-ZE20PD2U UPC:793442202568 Patented & Pats. Pend.

3 699 kr

Incl. VAT

Options

Locking powered dock featuring GDS® Technology™ with data and charging capabilities for the Zebra ET401, and ET40 & ET45 8" enterprise tablets with IntelliSkin® Next Generation protective sleeve via USB Type-C for power and dual USB Type A connector for adding up to 2 peripherals MIL-STD 810G Shock and Vibration tested
When connected to a power source, integrated pogo pins provide power to the device while docked Dock accommodates tablet add-ons such as the Expansion Back and PowerPack Battery tablet scanning works while tablet is docked
Compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm ball and socket technology allows for near-infinite adjustability
Built-in 2-hole mounting plate for additional device mounting such as a phone compatible with RAM® 2-hole diamond bases and accessory side bracket
Backed by a 3-year warranty

Related RAM® Components

RAM® Temp-Right™ Dock Heating Module fo...

RAM® Vent-Temp™ with Back Dock Connecti...

RAM® Vent-Temp™ with Front Dock Connect...

Information

Information
Compatibility
Complete Your Solution
Resources

Featuring GDS® Technology™ for data and charging capabilities and a key lock for theft deterrence, the GDS® Vehicle Dock works with the Zebra ET401, ET40, and ET45 10" enterprise tablets with an IntelliSkin® protective sleeve. This dock allows you to connect up to two desired peripherals while keeping the device charged through the pogo pin contacts when the device is docked. Power is provided by connecting to the dock's USB Type-C connector, while peripheral support is provided by the built-in dual USB Type-A cable. The dock also allows the tablet's scanning function to work on the side, as well as tablet add-ons such as the Zebra Expansion Back and PowerPack Battery. This vehicle dock is compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm in order to complete your mounting solution. Take the solution a step further by taking advantage of the built-in 2-hole mounting plate compatible with RAM® 2-hole diamond base for additional device mounting such as a phone or other handheld device. Always Protected. Always Connected.®

hardware included	(2) Keys (1) Side bracket for accessory mounting (4) #8-32 x 5/8” Machine Screws (2) #8-32 x 1/2” Machine Screws (6) #8-32 Nylock Nuts (4) #10-24 x 5/8” Machine Screws (4) #10-24 Nylock Nuts (2) Small Cable Ties
hole pattern	75 x 75mm VESA 4-Hole AMPS: 1.181" x 1.496"
materials	High strength composite
packaging type	Poly Bag
output voltage	5V - 20V @ 3A
power output	60W
input connector	USB Type-C
input cable length	215mm
output connector	(2) USB 2.0 Type A
output cable length	215mm
peripheral output	900mA (per port)
transfer speed	12Mbps
certifications	RoHS WEEE FCC CE ICES UKCA
Warranty	3 year warranty
Weight	0.771 kg
Additional Information	IntelliSkin® is required for this dock. See RAM-GDS-SKIN-ZE20C-NG for compatible IntelliSkin®.

hardware included	(2) Keys (1) Side bracket for accessory mounting (4) #8-32 x 5/8” Machine Screws (2) #8-32 x 1/2” Machine Screws (6) #8-32 Nylock Nuts (4) #10-24 x 5/8” Machine Screws (4) #10-24 Nylock Nuts (2) Small Cable Ties
hole pattern	75 x 75mm VESA 4-Hole AMPS: 1.181" x 1.496"
materials	High strength composite
packaging type	Poly Bag
output voltage	5V - 20V @ 3A
power output	60W
input connector	USB Type-C
input cable length	215mm
output connector	(2) USB 2.0 Type A
output cable length	215mm
peripheral output	900mA (per port)
transfer speed	12Mbps
certifications	RoHS WEEE FCC CE ICES UKCA
Warranty	3 year warranty
Weight	0.771 kg
Additional Information	IntelliSkin® is required for this dock. See RAM-GDS-SKIN-ZE20C-NG for compatible IntelliSkin®.
