RAM® Tough-Dock™ Power + Data for Zebra ET401 & ET4x 10"

Part#:RAM-HOL-ZE21PDU UPC:793442923821 Patented & Pats. Pend.

RAM-HOL-ZE21PDU:RAM-HOL-ZE21PDU_2:RAM Tough-Dock™ Power + Data for Zebra ET401 & ET4x 10"

RAM-HOL-ZE21PDU:RAM-HOL-ZE21PDU_3:RAM Tough-Dock™ Power + Data for Zebra ET401 & ET4x 10"

RAM-HOL-ZE21PDU:RAM-HOL-ZE21PDU_4:RAM Tough-Dock™ Power + Data for Zebra ET401 & ET4x 10"

RAM-HOL-ZE21PDU:RAM-HOL-ZE21PDU_5:RAM Tough-Dock™ Power + Data for Zebra ET401 & ET4x 10"

RAM® Tough-Dock™ Power + Data for Zebra ET401 & ET4x 10"

Part#:RAM-HOL-ZE21PDU UPC:793442923821 Patented & Pats. Pend.

2 999 kr

Incl. VAT

Options

RAM® Tough-Dock™ with EZ-Roll'r™ design with data and charging capabilities for the Zebra ET401 with RAM® Skin™, and ET40 & ET45 10" enterprise tablets with Rugged Frame via DC 5.5mm power jack and USB Type A connector for adding a peripheral MIL-STD 810G Shock and Vibration tested
When connected to a power source, integrated pogo pins provide power to the device while docked Dock accommodates tablet add-ons such as the Expansion Back and PowerPack Battery tablet scanning works while tablet is docked
Compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm ball and socket technology allows for near-infinite adjustability
Built-in 2-hole mounting plate for additional device mounting such as a phone compatible with RAM® 2-hole diamond bases and accessory side bracket
Backed by a 3-year warranty

Related RAM® Components

GDS® Hand-Stand™ for Zebra ET401 & ET4x...

GDS® Hand Strap Accessory for Zebra ET4...

GDS® Hand-Stand™ Magnetic Accessory for...

GDS® Roto-Mag™ 3-in-1 Grip Handle Acces...

RAM® Temp-Right™ Dock Heating Module fo...

RAM® Vent-Temp™ with Back Dock Connecti...

Information

Information
Compatibility
Complete Your Solution
Resources

Featuring data and charging capabilities, the RAM® Tough-Dock™ for Zebra ET40 & ET45 10" enterprise tablets with Rugged Frame allows you to connect a desired peripheral while keeping the device charged through the pogo pin contacts when the device is docked. Power is provided by connecting to the dock's 5.5mm DC power jack, while peripheral support is provided by the built-in USB Type-A cable. The dock also allows the tablet's scanning function to work on the side, as well as tablet add-ons such as the Zebra Expansion Back and PowerPack Battery. This vehicle dock is compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm in order to complete your mounting solution. Take the solution a step further by taking advantage of the built-in 2-hole mounting plate compatible with RAM® 2-hole diamond base for additional device mounting such as a phone or other handheld device.

hardware included	(1) Side bracket for accessory mounting (4) #8-32 x 5/8” Machine Screws (2) #8-32 x 1/2” Machine Screws (6) #8-32 Nylock Nuts (4) #10-24 x 5/8” Machine Screws (4) #10-24 Nylock Nuts (2) Small Cable Ties
hole pattern	75 x 75mm VESA 4-Hole AMPS: 1.181" x 1.496"
materials	High strength composite
packaging type	Poly Bag
input connector	5.5mm DC Connector
input cable length	1 Meter
output connector	USB 2.0 Type A
output cable length	242mm
peripheral output	500mA
transfer speed	12Mbps
certifications	RoHS WEEE CE UKCA
Warranty	3 year warranty
Weight	0.703 kg
Additional Information	To support the tablet without the Rugged Frame, see RAP-INSERT-ZE21U. This dock is not compatible with IntelliSkin®. For IntelliSkin® with GDS® Tech™, see RAM-GDS-DOCK-ZE21PDU.

hardware included	(1) Side bracket for accessory mounting (4) #8-32 x 5/8” Machine Screws (2) #8-32 x 1/2” Machine Screws (6) #8-32 Nylock Nuts (4) #10-24 x 5/8” Machine Screws (4) #10-24 Nylock Nuts (2) Small Cable Ties
hole pattern	75 x 75mm VESA 4-Hole AMPS: 1.181" x 1.496"
materials	High strength composite
packaging type	Poly Bag
input connector	5.5mm DC Connector
input cable length	1 Meter
output connector	USB 2.0 Type A
output cable length	242mm
peripheral output	500mA
transfer speed	12Mbps
certifications	RoHS WEEE CE UKCA
Warranty	3 year warranty
Weight	0.703 kg
Additional Information	To support the tablet without the Rugged Frame, see RAP-INSERT-ZE21U. This dock is not compatible with IntelliSkin®. For IntelliSkin® with GDS® Tech™, see RAM-GDS-DOCK-ZE21PDU.
