RAM® Pin-Lock™ Marine Electronic Mount - D Size Short
Part#:RAM-S-D-111U-C UPC:793442945274
Arm Length
Short Arm Medium Arm
Ball size D
2 869 kr
Incl. VAT

On request

This item is available on request. Leave your email and/or phone number and we’ll get back to you — it may already be on order or ready to assemble from parts in stock. If we need to source it specially, lead time is typically 6–8 weeks.

Looking for a faster option? Alternatives such as components or a different arm length are often available — contact us and we’ll help you find the right fit.

RAM® Hi-Torq™ Wrench for D Size Socket Arms
Recommended add-on
RAM® Hi-Torq™ Wrench for D Size Socket Arms
519 kr
Details
Related RAM® Products
RAM® Hi-Torq™ Wrench for D Size Socket Arms
RAM® Hi-Torq™ Wrench for D Size Socket ...
RAM® Pin-Lock™ Security Nut for D & E Size Socket Arms
RAM® Pin-Lock™ Security Nut for D & E S...
RAM® Cable Manager for Large Electronic Mounts
RAM® Cable Manager for Large Electronic...
RAM® Tough-Mag™ 48MM 4-Point Magnetic Mounting Base
RAM® Tough-Mag™ 48MM 4-Point Magnetic M...
RAM® 4" Offset Vehicle Base Riser
RAM® 4" Offset Vehicle Base Riser
RAM® 7" Offset Vehicle Base Riser
RAM® 7" Offset Vehicle Base Riser
The RAM-S-D-111U-C consists of a 3.68" diameter round base, SHORT LENGTH double socket arm, 11" x 3" rectangular base, RAM mixed combination Pin-Lock™ security nut and key knob. The round base contains pre-drilled holes, including two holes at 180 degrees and three holes at 120 degrees. The rectangle base contains different combinations of pre-drilled holes which will match up to many electronic devices and mounts, including Marine GPS, CB Radios, Ham Radios, Gimbal Brackets and more.
hardware included

(1) RAM Pin-Lock Security Key
(4) .312" x .187" Shoulder Washers
product dimensions

Overall Length: 8.125"
socket to socket length

3.6"
hole pattern

See Drawings
plate size

Top Plate: 3" x 11"
Bottom Plate: 3.68" Diameter
ball size

D Size (2.25")
weight capacity

Standard Use: 6 lbs
Heavy-Duty Use: 5 lbs
materials

Marine-grade aluminum
packaging type

Poly Bag
Weight

2.028 kg
Additional information
The 11" x 3" rectangle base is a universal mounting bracket with a selection of mounting hole locations. In certain applications additional holes may need to be drilled for proper fit with your electronic device.
